Product Details:
|
| Product Name: | Silicone Coated Glass Fiber Fabric, | Max Width: | 1000mm |
|---|---|---|---|
| Yarn Tyoe: | E-glass Fiberglass Fabric | Color: | Red, Grey, Black,White |
| Weave: | Electric Insulation Non-metallic Compensator | Coating: | Silicone Rubber Coating |
| Application: | Conveyor Belt And Expansion Joints | Packing: | PVC Package |
| Standing Temperature: | -70-260Degree | Surface Treatment: | Silicon Coated |
| Highlight: | Red Silicone Coated Fiberglass Cloth,Silicone Rubber Coated Fiberglass Fabric,Silicone Coated Fiberglass Cloth ISO |
||
Silicone Rubber Coated Fiberglass Fabric Used For Removable or Reusable Insulation Jackets
Product Description
Specially formulated silicone rubber is used to coat or impregnate one or both sides of fiberglass fabrics for applications requiring heat resistance, spark safety, chemical resistance, or abrasion resistance. The operating temperature is -50°C to +250°C normal. Due to its good heat resistance, weather resistance, moisture resistance, and acid and alkali chemical resistance, as well as good flexibility and abrasion resistance, our silicone-coated fiberglass fabrics can be directly used in the following applications
Technique Data Sheets
|
Item |
Technical Requirement |
|
Thickness(mm) |
±0.05 |
|
Width(mm) |
1000±10 |
|
Length(m/roll) |
50±0.5 |
|
Weight(g/m2) |
3300±50 |
|
Weave |
Plain |
|
Color |
Red |
|
℃ Cloth Temperature Resistance |
550℃ |
|
℃ Silicone Coating Temperature Resistance |
260℃ |
Properties
Heat resistant
High mechanical strength
Anti-aging
Soft and can be cut
High dielectric strength
Silicone Coating Fiberglass Fabric Application
Removable or reusable insulation jackets, mattresses, and pads; Fabric expansion joints and compensators;
Fabric ductwork connector;
Furnace curtains, welding curtains, welding blankets, and fire blankets;
Protective air cargo covers;
Noise control barriers;
Weather-proof or moisture-proof covers;
Firefighting apparel
Our advantages
Our company has a lot of experience in this field. We have been working in this field for about twenty years.
We have strict quality control.
Our factory has sufficient production capacity.
We have many customers all over the world. We are happy to serve new customers.
If you need acid and alkali-resistant coating, we can also provide you with EPDM fluorine rubber coating, etc.
Much More Related Silicone Coating Products with Different Thickness
| Product Name | Thickness (mm) | Weight (g/m2) |
| Single-Sided Silicone Coating Fiberglass Cloth | 0.9 | 1600 |
| 1 | 1800 | |
| 1.1 | 1850 | |
| 1.3 | 2050 | |
| 1.5 | 2560 | |
| 2 | 2900 | |
| 2.5 | 3400 | |
| Double-Sided Silicone Coating Fiberglass Cloth | 0.6 | 850 |
| 0.8 | 650 | |
| 1 | 1820 | |
| 1.1 | 1850 | |
| 1.5 | 2600 | |
| 2 | 3300 | |
| 2.5 | 4100 |
By thickness, we have two categories of products. One kind has a thickness of over 1mm and another kind has a thickness of below 1mm. You can choose the thickness by the occasion you use.
RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have a third party fire inspection report
3. How to package your product?
A: We pack the product in a carton or pvc bag. We can also pack according to customer's requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
