Product Details:
|
| Product Name: | Wire Reinforced Fiberglass Fabric For Fire Curtain | Width: | 1000 To 2000mm |
|---|---|---|---|
| Yarn Type: | E-glass Fiberglass Fabric With 316 Stainless Steel | Weave Structure: | Satin Weave |
| Feature: | High Temperature Resistant, Anti-abrasion | Satinless Type: | 316 Stainless Steel Wire |
| Standing Temperature: | 750℃ | Application: | Fire Curtains, Welding Blanket, Smoke Screen |
Stainless Steel Wire M850 1-Side 120gsm Grey Silicone Coating That Used For Removale Jacket And Smoke Curtain
Product Description
Stainless steel wire M850 is made of alkali-free glass fiber yarn and 316L stainless steel wire to increase tensile force. It is an inorganic fiber with a SiO2 content of more than 60%. It is resistant to high temperatures and can withstand temperatures up to 700°C. Because of its good chemical stability, high temperature resistance and ablation resistance, it is widely used in aerospace, metallurgy, chemical industry, building materials, fire protection and other industries.
50g/m2 PU coating on each side
Pu coating withstand 1100℃ instantaneously
Coated fiberglass fabric resist most acids
Chemical/Oil resistant
Washable, durable
Heat resistant
| Total weight | 200 g/m2 to 2000 g/m2 |
| Thickness | 0.2 mm to 3mm |
| Color | grey, white or golden |
| Fire resistance | high temperature resistant |
| Working temperature | 650C |
| Coating | PU, vermiculite, silicone, or silica coated, etc. |
| Standard widths | from 100cm to 200cm or customized |
Application
Welding blanket
Fire curtain / doors
Expansion joints
Disposal of dust
Technique Data Sheet for Stainless Steel Wire Fiberglass Cloth
| Items | Technical Requirement |
| Width | 100cm |
| Cloth Thickness | 0.8±0.05 mm |
| Cloth Weight | 9500g/m2 |
| Warp Yarn | 150 Tex + Stainless Wire |
| Weft Yarn | 150 Tex + Stainless Wire |
| Warp and Weft Density | 39*38 Ends/In |
| Warp Tensile Strength [25*200mm] | 2200N/2.5cm |
| Weft Tensile Strength [25*200mm] | 2100N/2.5cm |
| Temperature Resistance | 700oC |
Much More Related Stainless Steel FIberglass Cloth
| Product Type | Thickness mm | Weight g/m2 | Weave |
| PW05 SS | 0.5 | 455 | Plain |
| 666 SS | 0.6 | 630 | 8H Satin |
| 666 C SS | 0.6 | 630 | 8H Satin |
| M860W SS | 0.8 | 820 | Dougle Weft Yarn |
| M860 SS | 0.75 | 820 | 8H Satin |
| M860C SS | 0.8 | 820 | Close To Satin |
| M30 SS | 1.2 | 1050 | Plain |
| Other thicknesses can be customized upon request | |||
More Detail Images
Packing
Why Choose Us?
With a complete industrial chain, we can totally control the product quality and delivery time.
High quality products
ISO9001 2015 Certification
100% Testing before shipment, All products must pass the factory test
Different Sized of materials can be provided according to customer needs
RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have a third party fire inspection report
3. How to package your product?
A: We pack the product in a carton or PVC bag. We can also pack according to customers' requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
