Product Details:
|
| Product Name: | Wire Reinforced Fiberglass Fabric For Fire Curtain | Width: | 1000 To 2000mm |
|---|---|---|---|
| Yarn Type: | E-glass Fiberglass Fabric With 316 Stainless Steel | Weave Structure: | Satin Weave |
| Feature: | High Temperature Resistant, Anti-abrasion | Satinless Type: | 316 Stainless Steel Wire |
| Standing Temperature: | 750℃ | Application: | Fire Curtains, Welding Blanket, Smoke Screen |
Stainless Steel Wire M850 1-Side 120gsm Grey Silicone Coating That Used For Removale Jacket And Smoke Curtain
Product Description
Silicone rubber has excellent heat insulation, heat resistance, and weather resistance, and can be used as a coating for industrial fiberglass fabrics. The fabric will have new properties and exhibit high performance through silicone rubber coating, such as oxygen, non-stick, anti-corrosion, lightweight and weather resistance. Has been widely used in petroleum, chemical industry, construction, aerospace, machinery, metallurgy, electrical insulation and other fields.
Life-time: 10 years(under normal environment)
Standing temperature: -70C to 280℃
Dielectric constant: 3-3.2
Breakdown voltage: 20-50KV/MM
Low shrinkage:＜1%
Color: Red, gray, blue, black, orange, white,yellow or Pantone color
| Total weight | 200 g/m2 to 2000 g/m2 |
| Thickness | 0.2 mm to 3mm |
| Color | grey, white or golden |
| Fire resistance | high temperature resistant |
| Working temperature | 650C |
| Coating | PU, vermiculite, silicone, or silica coated, etc. |
| Standard widths | from 100cm to 200cm or customized |
Application
Welding blanket
Fire curtain / doors
Expansion joints
Disposal of dust
Technique Data Sheet for Stainless Steel Wire Fiberglass Cloth
| Items | Technical Requirement |
| Width | 100cm |
| Cloth Thickness | 0.8±0.05 mm |
| Cloth Weight | 9500g/m2 |
| Warp Yarn | 150 Tex + Stainless Wire |
| Weft Yarn | 150 Tex + Stainless Wire |
| Warp and Weft Density | 39*38 Ends/In |
| Warp Tensile Strength [25*200mm] | 2200N/2.5cm |
| Weft Tensile Strength [25*200mm] | 2100N/2.5cm |
| Temperature Resistance | 700oC |
Much More Related Stainless Steel FIberglass Cloth
| Product Type | Thickness mm | Weight g/m2 | Weave |
| PW05 SS | 0.5 | 455 | Plain |
| 666 SS | 0.6 | 630 | 8H Satin |
| 666 C SS | 0.6 | 630 | 8H Satin |
| M860W SS | 0.8 | 820 | Dougle Weft Yarn |
| M860 SS | 0.75 | 820 | 8H Satin |
| M860C SS | 0.8 | 820 | Close To Satin |
| M30 SS | 1.2 | 1050 | Plain |
| Other thicknesses can be customized upon request | |||
More Detail Images
Packing
Why Choose Us?
With a complete industrial chain, we can totally control the product quality and delivery time.
High quality products
ISO9001 2015 Certification
100% Testing before shipment, All products must pass the factory test
Different Sized of materials can be provided according to customer needs
RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have a third party fire inspection report
3. How to package your product?
A: We pack the product in a carton or PVC bag. We can also pack according to customers' requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
