Product Details:
|
| Features: | Good Acid And Alkaline Resistance | Product Name: | 4602 Filter Fiberglass Cloth |
|---|---|---|---|
| Feature: | Good Acid And Alkaline Resistance | Weight: | 435gsm |
| Thread Count: | 46*25.4 Ends/Inch | Application: | Building Material Shops, Manufacturing Plant, Printing Shops, Costruction Works |
| Thickness: | 0.43mm | Working Temperature: | 550 Degrees |
| High Light: | 4602 Fiberglass Filter Fabric,Filter Press Cloth 435gsm,Alkaline Resistance Fiberglass Filter Fabric |
||
Fiberglass Filter Media For Dust Collection Bags
Product Description:
In a fabric dust collector, dust-laden gas is drawn through a breathable fabric, usually in the form of tubular bags of varying diameters and lengths, through which the gas passes through the fabric and retains the particles. During this process, the gas is filtered and the clean gas comes out of the dust collector/bag filter. The separation of solid particles from gases through textile filter media at very high temperatures is an essential part of industrial processes, helping to recover valuable materials and improve pollution control.
Features:
No contamination of the molten aluminum
Cost-effective & easy installation
Reduce turbulence & improve distribution and flow
Remove oxides and inclusions.
Excellent stiffness and toughness, good impact resistance
Well organized grid to ensure fine filtration
Application:
As the first filtration for primary smelting
Sand casting, gravity or low pressure die casting
The Technique for Style 4602 Fiberglass Filter Fabric Cloth
| Style 4602 | ||
| Item Model | 4602 Filter Fiberglass Cloth | |
| Description | Woven Fiberglass Cloth | |
| Weight | 435±15gsm | |
| Width | 440±10mm | |
| Thickness | 0.43mm | |
| Yarn Type | Warp | DE75-1/2 150TEX |
| Weft | TEX200 | |
| Thread Count | Warp | 46±2 ends/In |
| Weft | 25.4±2 picks/In | |
| Break Strength | Warp | 2000 N/2.5cm |
| Weft | 1400 N/2.5cm | |
| Length | 410m | |
| LOI | < 0.4% | |
| Working Temperature | ≤550℃ | |
How to choose glass fiber filter material cloth?
| Fabric thickness (mm) | 0.3 | 0.4 | 0.5 | 0.7 |
| Fabric Weight | 320 | 390 | 435 | 730 |
| Filtration Airspeed (m/min) | ≤0.4 | ≤0.45 | ≤0.5 | ≤0.7 |
Specifications:
Weight: 350gsm-750gsm
Finishing treatment: Make to order depending on the special condition of the dust collector
Work temp: 260-280ºC
Excellent acids, caustics, solvent, hydrocarbons, and abrasion resistance;
Well Hydrolysis resistance, excellent strength, oxidative resistance
Emission concentration : <50mg/m3
Service life: 1-2years
Why choose us?
First of all, We choose the raw fiberglass yarn from China's top 4 fiberglass manufacturers – China Jushi Co., Ltd. Chongqing Fiberglass, Taishan Fiberglass, and Taiwan glass company.
Secondly, We have enough high-speed looms to meet the output and product quality.
Finally, We specialize in the production of various fiberglass-based fabric products and provide Silicone, and PTFE coating treatment to customers in the United States and Europe
