Product Details:
|
| Product Name: | EW390-1 Filter Fiberglass Cloth | Feature: | Good Structural Stability |
|---|---|---|---|
| Weight: | 390gsm | Thread Count: | 54*28 Ends/Inch |
| Application: | Flame Retardant Fireproof Good Thermal Insulation | Proterties: | Good Performance In High Heat |
| Thickness: | 0.3mm | Working Temperature: | 550 Degrees |
| High Light: | Plain glass fibre fabric,Mica Base Cloth,High Temp glass fibre fabric |
||
EW390-1 High-Temperature Resistance Mica Base Cloth Plain Fiberglass Cloth Fabric
Product Description:
Glass fiber is made of the primary material of texturized yarn. Through the innovation of weaving craft, weaving a thick high-density fiberglass cloth, and then by surface treatment process and integer to meet the dusting filtration technology requirements on the process of flue gas purification. The fiber has the advantages of high filtration rate, excellent filter performance, long life, high waterproof, and low cost.
Features:
Good performance in high heat, flame resistance, and insulation
High performance in tensile strength
Good fabric stiffness, goof flatness
Decay Resistance
Low density, low dielectric constant, low dielectric losses
Good Resin Impregnation
Application:
The production can be used as a reinforcing material for fire-resistant cables and motor tape with excellent voltage resistance, temperature resistance.
The Technique for Style 4602 Fiberglass Filter Fabric Cloth
| Style 4602 | ||
| Item Model | 4602 Filter Fiberglass Cloth | |
| Description | Woven Fiberglass Cloth | |
| Weight | 435±15gsm | |
| Width | 440±10mm | |
| Thickness | 0.43mm | |
| Yarn Type | Warp | DE75-1/2 150TEX |
| Weft | TEX200 | |
| Thread Count | Warp | 46±2 ends/In |
| Weft | 25.4±2 picks/In | |
| Break Strength | Warp | 2000 N/2.5cm |
| Weft | 1400 N/2.5cm | |
| Length | 410m | |
| LOI | < 0.4% | |
| Working Temperature | ≤550℃ | |
How to choose glass fiber filter material cloth?
| Fabric thickness (mm) | 0.3 | 0.4 | 0.5 | 0.7 |
| Fabric Weight | 320 | 390 | 435 | 730 |
| Filtration Airspeed (m/min) | ≤0.4 | ≤0.45 | ≤0.5 | ≤0.7 |
Specifications:
Weight: 350gsm-750gsm
Finishing treatment: Make to order depending on the special condition of the dust collector
Work temp: 260-280ºC
Excellent acids, caustics, solvent, hydrocarbons, and abrasion resistance;
Well Hydrolysis resistance, excellent strength, oxidative resistance
Emission concentration : <50mg/m3
Service life: 1-2years
Why choose us?
First of all, We choose the raw fiberglass yarn from China's top 4 fiberglass manufacturers – China Jushi Co., Ltd. Chongqing Fiberglass, Taishan Fiberglass, and Taiwan glass company.
Secondly, We have enough high-speed looms to meet the output and product quality.
Finally, We specialize in the production of various fiberglass-based fabric products and provide Silicone, and PTFE coating treatment to customers in the United States and Europe
Weaving:
Advanced air-saving performance, and equipment operating costs are greatly reduced. Simple operation interface, advanced management system, automatic output monitoring, real-time production scheduling.
