Product Details:
|
| Product Name: | Silicone Coated Glass Fiber Fabric, | Base: | 630gsm Fiberglass Cloth |
|---|---|---|---|
| Wight: | 850gsm | Coating: | Silicone Rubber Coating |
| Color: | Black, Red, Grey, White | Width: | 39 Inches |
| High Light: | Silicone Rubber Coating Fiberglass Cloth,0.8mm Thermal Insulation Cloth,Fireproof Blanket Thermal Insulation Fabric |
||
Silicone Coated Fiberglass Fabric Thermal Insulation Materials
Product Description
850g/m2 silicone coated fiberglass fabric is made of 630g/m2 0.8mm fiberglass cloth which is woven in satin weaving type. The coating is red Silicone on two sides, 100/100g. In order to great surface application, we will add glitter in the silicone coating so the final surface will be more bright and glossy. E-glass fiberglass cloth has fire resistance, chemical resistance, and high tensile strength. So the total weight of the silicone-coated fabric is 850g/m2, thickness is 1mm.
Fiberglass fabric is able to withstand heat below 550℃ continuously. The silicone coating can be used below 260 degrees Celsius. It is fire resistant, abrasion resistant, and has electrical insulation. Silicone-coated fiberglass fabric is widely used for fire blankets, fabric expansion joints, engine insulation parts, and insulation jackets for generators and engines.
Technical Data Sheets
| Item | Silicone Coated Fiberglass Fabric |
| Material | E-glass Fiberglass Cloth |
| Basic Cloth | 630gsm |
| Weave | 8 H Satin |
| Thread Count (Ends/CM) | 18*12 ends/cm |
| Total Weight | 880g/m2 |
| Thickness | 0.8mm |
| Width | 100cm |
| Work Temperature |
Silicone below 260℃ Fiberglas cloth below 550℃ |
Product Features
Dimensional stability allows this fabric to have very low thermal shrinkage. It can be used for day after day high-temperature insulation.
Products Applications
Heat resistant blanket
Fireproof blanket
Welding protection
Fabric expansion joint
Electrical insulation cover materials
Removable thermal insulation jacket
