Product Details:
|
| Product Name: | Silicone Coated Glass Fiber Fabric, | Max Width: | 1000mm |
|---|---|---|---|
| Withstand Temperature: | -50°C To 260°C | Yarn Tyoe: | E-glass Fiberglass Fabric |
| Color: | Red, Grey, Black,White | Weave: | Electric Insulation Non-metallic Compensator |
| Coating: | Silicone Rubber Coating | Application: | Conveyor Belt And Expansion Joints |
| High Light: | Fireproof Silicone Coated Fabric,1.3mm silicone fiberglass fabric,Heat Resistance Silicone Coated Fabric |
||
Silicone Coated Glass Cloth , Fireproof Silicone Coated Glass Fiber Fabric Used for Expansion Joint
Product Description
Silicon-coated fiberglass cloth is woven with high-quality fiberglass base cloth and then coated or impregnated with specially formulated silicone rubber on one or both sides.
These fabrics have good flexibility, durability, non-toxicity, water and oil resistance, high-temperature resistance, abrasion resistance, and excellent chemical resistance to general chemicals. Can be used in applications with temperatures from -70°C to 260°C.
Shenghe Company is a Chinese manufacturer. We have been working in this field for many years. We specialize in the production of electronic glass fiber fabric weaving and also provide coated composite materials
Notice: Although the base fabric is rated 1,000° F at continuous operating temperature, the silicone coating is rated 500°F on a continuous basis.
Technique Data Sheets
|
Item |
Technical Requirement |
|
Thickness(mm) |
1.3±0.05 |
|
Width(mm) |
1000±10 |
|
Length(m/roll) |
50±0.5 |
|
Weight(g/m2) |
2600±50 |
|
Warp/weft density(thread/cm) |
20x10±1 |
|
Breaking Strength Warp: N/50mm Weft: N/50mm |
≥4700x2680 |
|
Weave |
Plain |
|
Color |
Grey |
|
℃ Cloth Temperature Resistance |
550℃ |
|
℃ Silicone Coating Temperature Resistance |
260℃ |
Properties
1. Material: Silicone rubber and fiberglass
1. Color: Red, black, white, and so on
2. Usage: Welding blanket, fire curtain, flexible joint, insulation jacket, fire doors, smoke hanging wall
3. Thickness:0.4mm-3.0mm
4. Roll length:50-100m
5. Package: Woven bag
6. Working temperature:260℃
7. Width:1m-2m
Silicone Coating Fiberglass Fabric Application
Silicone-coated fabric is made up of silicone rubber and fiberglass fabric. This product can work under 200℃ for a long time.It is widely used in industry. We can use it as a welding blanket. It is also very suitable for outdoor work because silicone rubber has good aging resistance.
If you need acid and alkali-resistant coating, we can also provide you with EPDM fluorine rubber coating, etc.
Much More Related Silicone Coating Products with Different Thickness
| Product Name | Thickness (mm) | Weight (g/m2) |
| Single-Sided Silicone Coating Fiberglass Cloth | 0.9 | 1600 |
| 1 | 1800 | |
| 1.1 | 1850 | |
| 1.3 | 2050 | |
| 1.5 | 2560 | |
| 2 | 2900 | |
| 2.5 | 3400 | |
| Double-Sided Silicone Coating Fiberglass Cloth | 0.6 | 850 |
| 0.8 | 650 | |
| 1 | 1820 | |
| 1.1 | 1850 | |
| 1.5 | 2600 | |
| 2 | 3300 | |
| 2.5 | 4100 |
RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have third party fire inspection report
3. How to package your product?
A: We pack the product in a carton or pvc bag. We can also pack according to customer's requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
