High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance

Certification
China SHENGHE(CHANGSHU)ENVIRONMENTAL TECHNOLOGY CO.,LTD certification
I'm Online Chat Now

High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance

High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance
High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance

Large Image :  High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance

Product Details:
Place of Origin: China
Brand Name: Shenghe
Certification: ISO 9001
Model Number: 1.3mm Single-Sided Silicone Coating Fiberglass Cloth
Payment & Shipping Terms:
Minimum Order Quantity: 50 Meters
Price: Negotiation
Packaging Details: Woven Bag
Delivery Time: This silicone fabric is cut to order and is not returnable. The high temperature material typically ships out in 1-5 business days.
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 1000 meters per day

High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance

Description
Product Name: Silicone Fiberglass Fabric Max Width: 1000mm
Withstand Temperature: -50°C To 260°C Roll Length: 30 Or 50metres Per Rol
Color: Red, Grey, Black,White Weave: Electric Insulation Non-metallic Compensator
Coating: One-side/ Two-side Silicone Rubber Coating Application: Wall/Roof Covering Cloth, Electrical Insulation,non- Metallic Comensation,anti-corrosion
High Light:

High Intensity Silicone Coated Fiberglass Cloth

,

silicone coated glass fibre cloth

,

1.3mm Silicone Coated Fiberglass Cloth

Temperature Resistace High-Intensity Silicone Coated Fiberglass Cloth





Product Description

Resistance to high temperatures and flame makes this Silicone-Coated Fiberglass Cloth great for a range of uses. Applications include removable insulation, pads, drop cloths, welding curtains, welding shields, welding, blankets, hose coverings, and gaskets. The fiberglass fabric roll features a satin weave and comes in gray. Made from high-quality materials, the cloth is built to last.



Technique Data Sheets



Item



Technical Requirement



Thickness(mm)

1.3±0.05



Width(mm)

1000±10



Length(m/roll)

50±0.5



Weight(g/m2)

2600±50



Warp/weft density(thread/cm)

20x10±1

Breaking Strength

Warp: N/50mm Weft: N/50mm

≥4700x2680



Weave

Plain



Color

Grey

Cloth Temperature Resistance

550

Silicone Coating Temperature Resistance

260



Properties

Fireproof

High Strength

Anti-Friction

Chemical Resistance

Heat Resistance

Temperature Resistance, It can continuously work under 260 C degrees

Weather ability: Resistance to ozone, oxygen, sunlight, and aging, long using life up to 10 years

Good Electric insulator, the dielectric constant3-3.2 breakdown voltage between 20-50KV/mm



Silicone Coating Fiberglass Fabric Application

Silicone-coated fabric is made up of silicone rubber and fiberglass fabric. This product can work under 200℃ for a long time. It is widely used in industry. We can use it as a welding blanket. It is also very suitable for outdoor work because silicone rubber has good aging resistance.



If you need acid and alkali-resistant coating, we can also provide you with EPDM fluorine rubber coating, etc.



High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance 0

High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance 1

High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance 2



High Intensity Silicone Coated Fiberglass Cloth Temperature Resistance 3



Much More Related Silicone Coating Products with Different Thickness

Product Name Thickness (mm) Weight (g/m2)
Single-Sided Silicone Coating Fiberglass Cloth 0.9 1600
1 1800
1.1 1850
1.3 2050
1.5 2560
2 2900
2.5 3400
Double-Sided Silicone Coating Fiberglass Cloth 0.6 850
0.8 650
1 1820
1.1 1850
1.5 2600
2 3300
2.5 4100

Please note that the silicone-coated fabric quality is based on its thickness. The weight is only for reference and varies in different production batches.

RFQ

1. How to get free samples?

A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.



2. Are your products certified?

A: Yes, we have a third party fire inspection report



3. How to package your product?

A: We pack the product in a carton or PVC bag. We can also pack according to customers' requirements.



4. Are you a manufacturer?

A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
