Product Details:
|
| Product Name: | Silicone Rubber Coated Glass Fiber Fabric | Max Width: | 1000mm |
|---|---|---|---|
| Withstand Temperature: | -50°C To 260°C | Roll Length: | 30 Or 50metres Per Rol |
| Color: | Red, Grey, Black,White | Weave: | Electric Insulation Non-metallic Compensator |
| Coating: | Silicone Rubber Coating | Application: | Conveyor Belt And Expansion Joints |
| High Light: | Single Side Silicone Coated Fiberglass Cloth,silicone coated fiberglass fabric ISO,Fireproof Silicone Coated Fiberglass Cloth |
||
High-Quality Single Side Silicone Coated Fiberglass Fabric(Cloth) For Fireproof
Product Description
Silicone-coated glass fiber fabric can be used as one kind of welding blanket material. It has very good performance in this field. First of all, it has good heat resistance, so we can use it to prevent the flame from spreading. At the same time, it has good aging resistance, it can be used for a long time. Due to the above advantages. Silicone-coated fiberglass fabrics are becoming more and more widely used. As one of the most experienced companies in the industry. We hope to provide our good service and products all over the world. We believe that good quality can win customers' trust.
Notice: Although the base fabric is rated 1,000° F at continuous operating temperature, the silicone coating is rated 500°F on a continuous basis.
Technique Data Sheets
|
Item |
Technical Requirement |
|
Thickness(mm) |
1.3±0.05 |
|
Width(mm) |
1000±10 |
|
Length(m/roll) |
50±0.5 |
|
Weight(g/m2) |
2600±50 |
|
Warp/weft density(thread/cm) |
20x10±1 |
|
Breaking Strength Warp: N/50mm Weft: N/50mm |
≥4700x2680 |
|
Weave |
Plain |
|
Color |
Grey |
|
℃ Cloth Temperature Resistance |
550℃ |
|
℃ Silicone Coating Temperature Resistance |
260℃ |
Properties
It is fiberglass fabric coated with a specially formulated silicone rubber. Unlike uncoated fabrics, this flame-retardant rubber will provide extended life and resistance to oil and water.
Silicone Coating Fiberglass Fabric Application
Silicone-coated fabric is made up of silicone rubber and fiberglass fabric. This product can work under 200℃ for a long time. It is widely used in industry. We can use it as a welding blanket. It is also very suitable for outdoor work because silicone rubber has good aging resistance.
If you need acid and alkali-resistant coating, we can also provide you with EPDM fluorine rubber coating, etc.
Much More Related Silicone Coating Products with Different Thickness
| Product Name | Thickness (mm) | Weight (g/m2) |
| Single-Sided Silicone Coating Fiberglass Cloth | 0.9 | 1600 |
| 1 | 1800 | |
| 1.1 | 1850 | |
| 1.3 | 2050 | |
| 1.5 | 2560 | |
| 2 | 2900 | |
| 2.5 | 3400 | |
| Double-Sided Silicone Coating Fiberglass Cloth | 0.6 | 850 |
| 0.8 | 650 | |
| 1 | 1820 | |
| 1.1 | 1850 | |
| 1.5 | 2600 | |
| 2 | 3300 | |
| 2.5 | 4100 |
RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have third party fire inspection report
3. How to package your product?
A: We pack the product in a carton or pvc bag. We can also pack according to customer's requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
