Product Details:
|
| Product Name: | Fiberglass Rope Seal | Roll Length: | 20 Meters |
|---|---|---|---|
| Performance: | Fire-proof And High Temperature | Raw Material: | 9um E-glass,red Silicone Rubber |
| Basic Yarn: | 100% E-glass | Dia: | 40mm |
| Application: | Hose And Cable Thermal Barriers | Flammability: | Pipe Protection |
| High Light: | Silicone Rubber Fiberglass Sleeving 4mm,40mm Fiberglass Braided Sleeving,Alkali Free Silicone Rubber Fiberglass Sleeving |
||
Alkali Free Silicone Rubber Fiberglass Sleeving 4mm Fiberglass Braided Sleeving
Description for High-Temperature Silicone Rubber Fiberglass Sleeving
High-temperature casing, also known as fire casing, silicone rubber glass fiber casing, is made of high-purity alkali-free glass fiber, and then the outer wall of the pipe is coated with silicone. After vulcanization, it can be used for a long time in the temperature range of -65°C - 300°C, and can maintain its soft elastic properties.
Operation Temperature
Continuous Operating Temperature: -65 ° C - 260 ° C
15-20 minutes: 1090 ° C
15-30 seconds: 1650 ° C
Technique Data
| Description: | Texturized fiberglass sleeve with silicone coating | |||||
| Contents: | 100% glass fiber and silicone rubber | |||||
| Yarn type: | 9 um | |||||
| Internal Diameter : | 30mm | |||||
| Thermal Conductivity | 0.035(w/(m.k) | |||||
| Continuous Temp resistance: | No more than 550 0C | |||||
| Freeze temp: | -50 0C | |||||
| Loss on Ignition | ≦3.52% | |||||
| Chemical composition | ||||||
| SiO2 | Al2O3 | CaO | MgO | R2O | Fe2O3 | |
| 67.3±0.5 % | 6.4±0.4% | 9.6±0.3% | 4.5±0.3 % | 11.8~16.1% | ≤0.4 | |
Features:
Superior Electrical Properties.
Good Expandability and Flexibility.
Chemical Resistance.
Extreme Abrasion Resistance.
Oil Resistance.
Self Extinguishable.
Application:
Mainly used in steel plants, smelters, glass, and other thermal places to protect the hose, hose assemblies and cables. It also helps maintain line temperature and reduce environmental overheating and overcooling.
Transportation (Aerospace, Auto, Locomotive, Heavy Equipment)
Metals, Iron & Steel
Oil & Gas
The Other Types Recommended:
| Dia (mm) | Internal Dia (mm) | Length (m) | Thickness(mm) | ||
| Silicone | Glass Yarn | ||||
| 1 | 6 | 6.5 | 20 | 0.6 | 1.0 |
| 2 | 8 | 8.5 | 20 | 0.8 | 1.0 |
| 3 | 10 | 10.5 | 20 | 0.8 | 1.0 |
| 4 | 12 | 12.5 | 20 | 0.8 | 1.2 |
| 5 | 15 | 15.5 | 20 | 0.9 | 1.2 |
| 6 | 20 | 20.5 | 20 | 0.9 | 1.4 |
| 7 | 22 | 22.5 | 20 | 0.9 | 1.4 |
| 8 | 25 | 25.5 | 20 | 1 | 1.6 |
| 9 | 30 | 30.5 | 20 | 1.1 | 1.8 |
| 10 | 32 | 32.5 | 20 | 1.2 | 1.8 |
| 11 | 35 | 35.5 | 20 | 1.1 | 2 |
| 12 | 40 | 40.5 | 20 | 1.2 | 2.1 |
| 13 | 45 | 45.5 | 20 | 1.2 | 2.2 |
| 14 | 50 | 51 | 20 | 1.2 | 2.3 |
| 15 | 55 | 56 | 20 | 1.3 | 2.4 |
| 16 | 60 | 61 | 20 | 1.3 | 2.5 |
| 17 | 65 | 66 | 20 | 1.3 | 2.6 |
| 18 | 70 | 71 | 20 | 1.4 | 2.7 |
