Product Details:
|
| Features: | High Temperature Resistance, Good Flame Retardant Ability | Product Name: | High Silica Fiberglass Cloth |
|---|---|---|---|
| Material: | High Silica Fiberglass Yarn | Treatment: | Acid Treated |
| Temperature Resistance /Working Temperature: | 1000℃ | Color: | Bron |
| Weight: | 600gsm | Application: | Welding And Molten Metal Splash Protection, Heat And Flame Shielding |
| High Light: | 18oz Fiberglass Cloth Heat Resistant,8HS Satin high temp fiberglass fabric,600gsm Fiberglass Cloth Heat Resistant |
||
18oz Fiberglass Cloth Heat Resistant For Fire Blanket Flame Resistant Door
1. Product Introduction
The high silicon fabric is woven from 96% pure SiO2 silicon fiber yarn, and the continuous working temperature is 1000 ℃. It is easy to manufacture and remains flexible after high temperature exposure, and provides excellent molten metal splash protection. High silica fabrics have many uses, from welding to metal cutting applications. High temperature textiles have been used in applications that protect against extreme high temperature environments, with excellent breaking strength and improved abrasion resistance. It also has excellent chemical resistance and electrical insulating properties.
2. Technique Data Sheets
|
Item |
Technical Requirement |
Test Result |
|
Width(mm) |
1000±10 |
1002 |
|
Weave Style |
8HS Satin |
8HS Satin |
|
Warp Counts (ends/cm) |
≥18 |
19 |
|
Fill Count |
≥13 |
14 |
|
Warp Breaking Strength (N/Inch) |
≥ 800 |
965 |
|
Weft Breaking Strength (N/Inch) |
≥ 500 |
643 |
|
Weight (g/m2) |
600± 30 |
616.67 |
|
Length (m) |
50.0 |
50.0 |
|
Thickness |
0.7 ± 0.1 |
0.724 |
|
Silica Content % |
≥ 96 |
97.8 |
|
Linear Shrinkage% |
5-10 |
5.2 |
|
Working Temperature |
1200 ℃ |
1200 ℃ |
|
Coating Pu |
0.8-1% |
0.86% |
3. Application
Welding Blankets, Curtains
Heat and Flange Shielding
Stress Relief
Gasket, Seal
Hose and Cable Protection
Protective Garments
4. Properties
Good performance in a high-temperature environment can be used as a fire curtain, welding blanket, removable heat insulation kit, or mat.
High temperature resistant;
High tensile strength;
Low thermal conductivity;
Low smoke emission.
5. Much More Related Products
| Product Name | Widths | Working Temperature | Weight g/m2 | SiO2 CONTENT |
| High Silica Cloth | 92 -100cm | 1000oC | 300 | >96% |
| High Silica Cloth | 92 -100cm | 1000oC | 450 | >96% |
| High Silica Cloth | 92 -100cm | 1000oC | 612 | >96% |
| High Silica Cloth | 92 -100cm | 1000oC | 880 | >96% |
| High Silica Cloth | 92 -100cm | 1000oC | 1100 | >96% |
| Medium Silica Cloth | 92 -100cm | 750oC | 600 | >70% |
| Medium Silica Cloth | 92 -100cm | 750oC | 700 | >70% |
| Medium Silica Cloth | 92 -100cm | 750oC | 1100 | >70% |
| Medium Silica Cloth | 92 -100cm | 750oC | 1200 | >70% |
6. Storage and Packing
7. Why Choose Us?
Your inquiry will be replied to within 24 hours
Well-trained and experienced staff to answer all your inquiries.
All our products have 1-year warranties.
Competitive prices based on the same quality.
Guarantee sample quality same as mass production quality.
8. RFQ
1. How to get free samples?
A: You can contact our sales staff. We can send you some samples for free. But we do not pay for shipping.
2. Are your products certified?
A: Yes, we have a third-party fire inspection report
3. How to package your product?
A: We pack the product in a carton or PVC bag. We can also pack according to customers' requirements.
4. Are you a manufacturer?
A: Yes, we are a Chinese manufacturer. We have advanced looms to provide basic cloth
