Product Details:
|
| Acid Resistance: | Excellent | Width: | 1270mm |
|---|---|---|---|
| Thickness: | 0.2mm | Weight: | 210g/m2 |
| Length: | 50m-100m | Alkali Resistance: | Excellent |
| Flexibility: | Excellent | Temperature Resistance: | 550℃ |
E Fiberglass Cloth is an excellent plain weave electronice fiberglass fabric, which is made from first-class fiberglass E-glass yarn and designed for electronic insulation. It has a 1270mm width and is uncoated, which demonstrates excellent flexibility and alkali resistance. With superior tensile strength, E Fiberglass Cloth is widely used in the insulation of electronic equipment, telecommunications, and machinery.
Shenghe's E-Glass Fiberglass Cloth (Model 7628) is a high temperature material that is certified with ISO 9001, offering excellent alkali resistance and plain weave. The thickness of the cloth is 0.2mm, and has an elongation of 2%-5%.
Shenghe's E-Glass Fiberglass Cloth (Model 7628) comes in minimum orders of 500 Meters, and the price is subject to negotiation. The product is packed in cartons loaded on pallets or according to customers' requirements. Delivery time is typically 1-5 business days. Payment terms are available through L/C, D/A, D/P, T/T.
| Property | Value |
|---|---|
| E-glass Fiberglass Cloth | Electrical Fiberglass Cloth |
| Acid Resistance | Excellent |
| Width | 1270mm |
| Weight | 210g/m2 |
| Thickness | 0.2mm |
| Weave | Plain |
| Length | 50m-100m |
| Alkali Resistance | Excellent |
| Elongation | 2%-5% |
| Material | Fiberglass |
| Tensile Strength | 1000N/5cm-3000N/5cm |
Shenghe is offering customized Electrical Fiberglass Cloth with the following features:
Shenghe is the best choice for your Electrical Fiberglass Cloth needs. Contact us today for more information!
We provide technical support and services for E Fiberglass Cloth. Our knowledgeable and experienced staff will provide you with the best advice and guidance, helping you to get the most out of your product.
We offer a variety of services, including:
If you have any questions or need assistance, please do not hesitate to contact us. We are always happy to help.
Packaging and Shipping for E Fiberglass Cloth:
E Fiberglass Cloth is packaged in sealed, heavy-duty plastic bags with labels. The bags are then placed in cardboard boxes that are labeled with the product name, quantity, and other relevant information. The boxes are then securely sealed with packing tape. The product is shipped via ground transportation in a climate-controlled truck.
6. We have dozens of E-glass fiberglass cloths which are closely woven. They are suitable for industries such as insulation, electronics, adhesive tape making. Here below are some typical styles:
Our machine brands are DORNIER, TOYOTA, and our production capacity is about 1.8 million square meters per month. Our fiberglass E-glass cloth offers an excellent balance between cost and performance. Welcome to develop new products with us. The following items are our main products.
| NO. | Style | Width, cm | Weight,g/m2 | Thickness, mm | Weaving type |
| 1 | 104 | 107 127 | 18.7±3.0 | 0.028 | Plain |
| 2 | 106 | 107 127 | 24.8±3.0 | 0.036 | Plain |
| 3 | 1070 | 107 127 | 33.4±3.0 | 0.055 | Plain |
| 4 | 1080 | 107 127 157 | 46.8±3.0 | 0.062 | Plain |
| 5 | 1280 | 107 127 157 | 53.6±3.0 | 0.064 | Plain |
| 6 | 2112 | 107 127 157 | 71.5±4.0 | 0.081 | Plain |
| 7 | 2113 | 107 127 157 | 79.3±4.0 | 0.080 | Plain |
| 8 | 3313 | 107 127 157 | 81.4±4.0 | 0.084 | Plain |
| 9 | 1674 | 107 127 157 207 254 | 98.0±4.0 | 0.100 | Plain |
| 10 | 2116 | 107 127 157 207 254 | 106.8±4.0 | 0.094 | Plain |
| 11 | 1165 | 107 127 157 207 254 | 121.0±8.8 | 0.110 | Plain |
| 12 | 1522 | 107 127 157 207 254 | 123.4±8.8 | 0.150 | Plain |
| 13 | 154【1211】 | 107 127 157 207 254 | 123.8±8.8 | 0.140 | Plain |
| 14 | 985 | 107 127 157 207 254 | 139.0±8.8 | 0.130 | Plain |
| 15 | 985A | 107 127 157 207 254 | 143.0±8.8 | 0.140 | Plain |
| 16 | 1652 | 107 127 157 207 254 | 140.0±8.8 | 0.114 | Plain |
| 17 | 1064 | 107 127 157 207 254 | 156.0±8.8 | 0.150 | Plain |
| 18 | 5430 | 107 127 157 207 254 | 180.0±8.8 | 0.153 | Plain |
| 19 | 7628L | 107 127 157 207 254 | 201.0±12.0 | 0.178 | 1/3 Twill |
| 20 | 7628T | 107 127 157 207 254 | 205.4±16.6 | 0.180 | Plain |
| 21 | 1528 | 107 127 157 207 254 | 211.9±16.6 | 0.165 | Plain |
| 22 | 7638H | 107 127 157 207 254 | 285.0±16.6 | 0.265 | Plain |
| 23 | 1142 | 107 127 157 207 254 | 290.4±16.6 | 0.279 | Plain |
| 24 | 7530 | 107 127 157 207 254 | 345.0±16.6 | 0.290 | Plain |
| 25 | 1523 | 107 127 157 207 254 | 392.0±16.6 | 0.340 | Plain |
| 26 | 162 | 107 127 157 207 254 | 400.0±20.0 | 0.381 | Plain |
| 27 | 1589 | 107 127 157 207 254 | 414.0±20.0 | 0.406 | Plain |
| 28 | 1564 | 107 127 157 207 254 | 420.4±20.0 | 0.380 | Plain |
