Product Details:
|
| Product Name: | Fiberglass Rope Seal | Roll Length: | 20 Meters |
|---|---|---|---|
| Performance: | Fire-proof And High Temperature | Raw Material: | 9um E-glass,red Silicone Rubber |
| Basic Yarn: | 100% E-glass | Dia: | 40mm |
| Application: | Hose And Cable Thermal Barriers | Flammability: | Pipe Protection |
| High Light: | 550 Degrees Silicone Fiberglass Sleeve,electrical wire fiberglass insulation sleeving,Heat Resistant Silicone Fiberglass Sleeve |
||
550 Degrees Heat Resistant Silicone Fiberglass Sleeve Insulation Cable Pipe Protection
Description for High-Temperature Silicone Rubber Fiberglass Sleeving
Made of 9um E fiberglass yarn coated with red silicone rubber.
High-temperature resistance up to 260C; and resistance to most chemical solvents
Used extensively as a conduit, hose, and cable protection sleeve, providing an excellent thermal barrier.
Good abrasion resistance is useful in heavy-duty applications where excellent mechanical and electrical properties are required.
Good mechanical properties and high dielectric strength make it an ideal material for applications such as transformer lead protection, motor coil leads, component isolation, and power wiring.
The mechanical properties and high dielectric strength of bushings make them the first choice for applications such as transformer lead protection, motor coil leads, component isolation, and power wiring.
Operation Temperature
Continuous Operating Temperature: -65 ° C - 260 ° C
15-20 minutes: 1090 ° C
15-30 seconds: 1650 ° C
Technique Data
| Description: | Texturized fiberglass sleeve with silicone coating | |||||
| Contents: | 100% glass fiber and silicone rubber | |||||
| Yarn type: | 9 um | |||||
| Internal Diameter : | 30mm | |||||
| Thermal Conductivity | 0.035(w/(m.k) | |||||
| Continuous Temp resistance: | No more than 550 0C | |||||
| Freeze temp: | -50 0C | |||||
| Loss on Ignition | ≦3.52% | |||||
| Chemical composition | ||||||
| SiO2 | Al2O3 | CaO | MgO | R2O | Fe2O3 | |
| 67.3±0.5 % | 6.4±0.4% | 9.6±0.3% | 4.5±0.3 % | 11.8~16.1% | ≤0.4 | |
Features:
It's non-combustible, resists most chemical solvents. A silicone fiberglass sleeve is an ideal material in heavy-duty applications that require outstanding mechanical and electrical properties, it has good abrasion resistance.
Application:
This type of sleeve is made from high-quality 9um diameter E fiberglass textile, with a silicone rubber coating and excellent performance on high-temperature resistance, they are used a lot as pipe, hose, and cable protection sleeves providing an excellent thermal barrier.
The Other Types Recommended:
| Dia (mm) | Internal Dia (mm) | Length (m) | Thickness(mm) | ||
| Silicone | Glass Yarn | ||||
| 1 | 6 | 6.5 | 20 | 0.6 | 1.0 |
| 2 | 8 | 8.5 | 20 | 0.8 | 1.0 |
| 3 | 10 | 10.5 | 20 | 0.8 | 1.0 |
| 4 | 12 | 12.5 | 20 | 0.8 | 1.2 |
| 5 | 15 | 15.5 | 20 | 0.9 | 1.2 |
| 6 | 20 | 20.5 | 20 | 0.9 | 1.4 |
| 7 | 22 | 22.5 | 20 | 0.9 | 1.4 |
| 8 | 25 | 25.5 | 20 | 1 | 1.6 |
| 9 | 30 | 30.5 | 20 | 1.1 | 1.8 |
| 10 | 32 | 32.5 | 20 | 1.2 | 1.8 |
| 11 | 35 | 35.5 | 20 | 1.1 | 2 |
| 12 | 40 | 40.5 | 20 | 1.2 | 2.1 |
| 13 | 45 | 45.5 | 20 | 1.2 | 2.2 |
| 14 | 50 | 51 | 20 | 1.2 | 2.3 |
| 15 | 55 | 56 | 20 | 1.3 | 2.4 |
| 16 | 60 | 61 | 20 | 1.3 | 2.5 |
| 17 | 65 | 66 | 20 | 1.3 | 2.6 |
| 18 | 70 | 71 | 20 | 1.4 | 2.7 |
