Product Details:
|
| Product Name: | Heat Resistant Hose And Cable Protective Pyrojacket Fire Sleeve | Size: | 6-150mm |
|---|---|---|---|
| Performance: | Fire-proof And High Temperature | Aging Test: | 260ºC,6 Hrs Without Crackle |
| Continuous Operating Temperature: | -10ºC+200ºC | Name: | Hose Fire Sleeve |
| Application: | Used To Protect Hoses, Wires And Cables | Flammability: | Impede Heat Radiation Of Flame |
| High Light: | Fiberglass High Temp Wire Sleeve,Heat shield high temp cable sleeve,Silicone Coated High Temp Wire Sleeve |
||
Silicone coated fiberglass high temp wire exhaust insulation heat shield silicone fire sleeve
Description for High-Temperature Silicone Rubber Fiberglass Sleeving
Economic Silicone Rubber Fiberglass Braided Fire Sleeve is constructed from a high bulk glass fiber braided sleeve. Excellent modulus of elasticity makes it an excellent choice for bundling hoses, tubes, and cables in a variety of hostile environments. Protect your personnel and cut your energy loss economic Grade Fire Sleeve is an insulation property that provides personnel with effective protection against burns from hot hoses and flexible steam lines while reducing heat energy losses. Always wear safety glasses, dust mask, gloves, and long sleeves are recommended when handling this product
| Inner diameter | 10mm-115mm |
| Color | Red, black, other colors can be made according to customer's need, nylon fastening optional color: white or black |
| Work temperature | Can used continuously at - 75 ° C to 260 ° C, short moment resistance can be up to 1650 ° C |
| Nominal voltage | 7kv--25 kv. |
| Product properties | Fire prevention, flame retardant, heat insulation, insulation, anti-aging, prevent splas |
Operation Temperature
Continuous Operating Temperature: -65 ° C - 260 ° C
15-20 minutes: 1090 ° C
15-30 seconds: 1650 ° C
Technique Data
| Description: | Texturized fiberglass sleeve with silicone coating | |||||
| Contents: | 100% glass fiber and silicone rubber | |||||
| Yarn type: | 9 um | |||||
| Internal Diameter : | 30mm | |||||
| Thermal Conductivity | 0.035(w/(m.k) | |||||
| Continuous Temp resistance: | No more than 550 0C | |||||
| Freeze temp: | -50 0C | |||||
| Loss on Ignition | ≦3.52% | |||||
| Chemical composition | ||||||
| SiO2 | Al2O3 | CaO | MgO | R2O | Fe2O3 | |
| 67.3±0.5 % | 6.4±0.4% | 9.6±0.3% | 4.5±0.3 % | 11.8~16.1% | ≤0.4 | |
Features:
1, Fireproof, flame retardant, heat insulation.
2, Heat prevention, insulation, anti-aging
3, Withstand melting metal splash
4, Withstand strong heat source and flame.
5, Anti-acid and anti-alkali
Application:
It also provides a high degree of insulation value, protecting hot, cold or cryogenic lines, pipes and tubing from heat or cold loss, providing energy savings and abrasion resistance
Detail Images
The Other Types Recommended:
| Dia (mm) | Internal Dia (mm) | Length (m) | Thickness(mm) | ||
| Silicone | Glass Yarn | ||||
| 1 | 6 | 6.5 | 20 | 0.6 | 1.0 |
| 2 | 8 | 8.5 | 20 | 0.8 | 1.0 |
| 3 | 10 | 10.5 | 20 | 0.8 | 1.0 |
| 4 | 12 | 12.5 | 20 | 0.8 | 1.2 |
| 5 | 15 | 15.5 | 20 | 0.9 | 1.2 |
| 6 | 20 | 20.5 | 20 | 0.9 | 1.4 |
| 7 | 22 | 22.5 | 20 | 0.9 | 1.4 |
| 8 | 25 | 25.5 | 20 | 1 | 1.6 |
| 9 | 30 | 30.5 | 20 | 1.1 | 1.8 |
| 10 | 32 | 32.5 | 20 | 1.2 | 1.8 |
| 11 | 35 | 35.5 | 20 | 1.1 | 2 |
| 12 | 40 | 40.5 | 20 | 1.2 | 2.1 |
| 13 | 45 | 45.5 | 20 | 1.2 | 2.2 |
| 14 | 50 | 51 | 20 | 1.2 | 2.3 |
| 15 | 55 | 56 | 20 | 1.3 | 2.4 |
| 16 | 60 | 61 | 20 | 1.3 | 2.5 |
| 17 | 65 | 66 | 20 | 1.3 | 2.6 |
| 18 | 70 | 71 | 20 | 1.4 | 2.7 |
